Got Aftermarket Gauges?; Post them up
Topic Started: Feb 15 2010, 08:20 AM (877 Views)
frax
Member Avatar
Stage 6
Im looking at getting some gauges and was wondering where everyone else has mounted their gauges? cos as we all know gauges not done right can look fairly ugly. so if you have some gauges in you 111 can you post up some pics?
Offline Profile Quote Post Goto Top

1i1
Member Avatar
NZ Toyota Parts Guy

Posted Image

In my sedan its where the stereo would be in your car so not ideal. I always like seeing one or two on top of the steering coloumn. Nice and easy to see and if placed correctly doesn't block anything
Offline Profile Quote Post Goto Top

n2o
Member Avatar
mechanical n00b
get something like this, fits in a single din slot
google "Defi DIN Gauge"

Posted Image
Offline Profile Quote Post Goto Top

frax
Member Avatar
Stage 6
im running a double din head unit.
Offline Profile Quote Post Goto Top

fender86
Member Avatar
Stage 5
@frax: chuck them all into ur glove box like what the Japanese used to do back in the days XD

I like those defi din gauges.. its nice and simple :D
Edited by fender86, Feb 16 2010, 09:16 AM.
Offline Profile Quote Post Goto Top

BZR4AGE
Member Avatar
JDM TODA
Defi Din Gauge = EXPENSIVE, and if I remember correctly their price excludes sensors! and their sensors are EXPENSIVE!

just got oil pressure and oil temp from autometer. Pro Sport series - pretty basic nothing fancy, just needed something for trackdays. $250NZD delivered...electric gauge too! will post pics once wired
Offline Profile Quote Post Goto Top

1i1
Member Avatar
NZ Toyota Parts Guy

ARC made a rear veiw mirror guage holder designed to hold four 60mm diameter guages....

It would mean you have no centre rear veiw mirror of course but thats minor detail
Edited by 1i1, Feb 17 2010, 01:05 AM.
Offline Profile Quote Post Goto Top

taz-20v
Member Avatar
Stage 6
Any more info on how people have there gauges installed to there cars??
Next on my list is gauges so I'm interested in this
Also what are peoples opinions on DEFI are they over priced or really as good as people say I know N20 has some so whats your opinion??
I want a god quality gauge for mine
Offline Profile Quote Post Goto Top

pergie
Member Avatar
Stage 5
got theses for my car not fitted yet
Posted Image
Offline Profile Quote Post Goto Top

taz-20v
Member Avatar
Stage 6
@pergie now those are some sexy gauges would Love somthing like that I'd say they cost you a pretty penny.I'm meant to go luck at my cuzins guages now to see if I'm buying them
Offline Profile Quote Post Goto Top

pergie
Member Avatar
Stage 5
taz-20v
May 5 2011, 09:05 PM
@pergie now those are some sexy gauges would Love somthing like that I'd say they cost you a pretty penny.I'm meant to go luck at my cuzins guages now to see if I'm buying them
ye u could say that 480 for the lot but i wanted something that doesnt stand out to much
Offline Profile Quote Post Goto Top

robcam
Member Avatar
96BZR

Defi certainly make good gauges. Greddy smi and Defi dasy chain gauges pretty much run all the same internals, sensors and control units.

Cost me about $350 NZ all up.

Here is my setup:

Posted Image

Posted Image

Posted Image

Posted Image
Offline Profile Quote Post Goto Top

1i1
Member Avatar
NZ Toyota Parts Guy

^ Nice and easy to see when driving :thumbsup:
Offline Profile Quote Post Goto Top

Ikenty
Member Avatar
BZ Touring Carib
I use these with the radio below.

Posted Image
Offline Profile Quote Post Goto Top

DreadAngel
Member Avatar
Han Lue
Defi make OEM and aftermarket...

They supply from memory Nismo, Mugen, TRD, I 'think' STi to name a few aftermarket guys.

They're not overpriced for what they are. Yes you can get an cheaper 'defi' style or what not. But the nightmares and issues I've dealt with when helping people install them just meh... Takes the shine of the price when you start spending more money to install it only to find out something needs to be replaced etc.
Offline Profile Quote Post Goto Top

supernova-dw


Defi of course of an excellent brand but not worth the price imo, I mean you can get equal quality for much less! People get hung up about the brand names and as a consequence these companies can sell for a very strong price! I'd probably go for something like Autometer or similar personally, kind of a middle of the range set up.
Offline Profile Quote Post Goto Top

taz-20v
Member Avatar
Stage 6
Well I went for Defi's in the end got a crazy good deal
The pics are in my build if u wana see
Offline Profile Quote Post Goto Top

DreadAngel
Member Avatar
Han Lue
Shop around for Defi 2nd hand, as long as the wiring and sensors aren't butchered, you'll get top stuff for a good price. As a Defi owner, you don't have to worry too much about price depreciation unless you've got a really old/unpopular model.
Offline Profile Quote Post Goto Top

taz-20v
Member Avatar
Stage 6
DreadAngel
May 6 2011, 09:49 AM
Shop around for Defi 2nd hand, as long as the wiring and sensors aren't butchered, you'll get top stuff for a good price. As a Defi owner, you don't have to worry too much about price depreciation unless you've got a really old/unpopular model.
I'm not sure of the model I bought but I've seen them working from the car I bought them from and there aways spot on
There he link model thats all I seam to know at the moment lol
Offline Profile Quote Post Goto Top

DreadAngel
Member Avatar
Han Lue
The Defi Link is the ones that don't black out when they're off =)

Defi BF Link is the ones that black out when they're off ;)

The latest is the Defi Advance series ;)
Offline Profile Quote Post Goto Top

taz-20v
Member Avatar
Stage 6
Thanks for that Info I have Defi Link BF
Offline Profile Quote Post Goto Top

taz-20v
Member Avatar
Stage 6
Right lads went to fit a Greddy gauge for a friend yesterday but I'm missing few pieces.
The gauge is to be used a an oil temp gauge but theres cut wires and sendors missing so I just want a few pointers
Is it possible for new senders and connections?or would it just be easier for him to use it as a water temp gauge
I think a few lads on the sit e have these gauges there a similar system to defi links.
Any help appreciated
Posted Image
Posted Image
Offline Profile Quote Post Goto Top

robcam
Member Avatar
96BZR

Red from the gauge connect to the constant 12v
Connect Orange & White wire from the gauge together then connect them to the an ignition triggered wire wire.
Black from the gauge connect to an earth

All wires can be found in the stereo loom. Just get a new temp sensor. (water / oil temp use the same sensor) any defi or greddy one will work.
Offline Profile Quote Post Goto Top

taz-20v
Member Avatar
Stage 6
Perfect Thanks for that
Does this gauge need to be connected up to a control box like a defi or is it possible to use solo?
Sorry for all the question rob but can you get me a pic of the sensor I need?
I have a pic here but I think this one i wrong

http://www.myhotmazda.com/Greddy/Performance-Accessories/Universal-Greddy-Oil-&-Water-Temp-Sensor-_-16401304/803522/
Edited by taz-20v, Aug 23 2011, 05:08 PM.
Offline Profile Quote Post Goto Top

robcam
Member Avatar
96BZR

taz-20v
Aug 23 2011, 04:53 PM
Perfect Thanks for that
Does this gauge need to be connected up to a control box like a defi or is it possible to use solo?
Sorry for all the question rob but can you get me a pic of the sensor I need?
I have a pic here but I think this one i wrong

http://www.myhotmazda.com/Greddy/Performance-Accessories/Universal-Greddy-Oil-&-Water-Temp-Sensor-_-16401304/803522/
For those particular gauges the sensor and power just plug straight into the gauge. (no control box)

That is the correct sensor the defi ones have the same plug but are a bronze colour.

Posted Image
Offline Profile Quote Post Goto Top
