hey guys looking for pictures of an ae101 arc induction box.
long story short bought an arc box last night looks diffent to the the one in all the threads.
so i want to find out what mine is before i have a word with the chap i bought it from
Offline Profile Quote Post Goto Top

robcam
Member Avatar
96BZR

ae101
Posted Image

ae111
Posted Image
Offline Profile Quote Post Goto Top

The Parrot


as in the induction box not the intake chamber.with the filter.
thanks man though.
Offline Profile Quote Post Goto Top

BZR4AGE
Member Avatar
JDM TODA
look at my build log
Offline Profile Quote Post Goto Top

The Parrot


it dosnt look like that. its weird.
it is similar but looks like it is cut in half.and the outlet is in the middle of the box.
Offline Profile Quote Post Goto Top

The Parrot


Posted Image

this is a picture of it.
Offline Profile Quote Post Goto Top

TRUENOSAM
Member Avatar
Stage 6
The Parrot
Sep 14 2010, 06:27 PM
it dosnt look like that. its weird.
it is similar but looks like it is cut in half.and the outlet is in the middle of the box.


They dont have a lower half mate. The bottom of the box is the filter


EDIT.That does not look like a AE111 box. This was mine

Posted Image
Edited by TRUENOSAM, Sep 14 2010, 06:37 PM.
Offline Profile Quote Post Goto Top

The Parrot


i dont mean bottom half.
i know trying to figure out what it is now.
Offline Profile Quote Post Goto Top

dkae
Stage 3
just got mine today, dose it just float in place ? seems the only thing holding it is the pipe going to the engine.
Offline Profile Quote Post Goto Top

The Parrot


yup . ok so the guy still recons its an ae111 arc. will just have to try it i guess. anyone have a picture of the outlet on the box thanks guys. want to see the bell mouth.
Offline Profile Quote Post Goto Top

TRUENOSAM
Member Avatar
Stage 6
The Parrot
Sep 24 2010, 11:18 PM
yup . ok so the guy still recons its an ae111 arc. will just have to try it i guess. anyone have a picture of the outlet on the box thanks guys. want to see the bell mouth.
Could he mean the Euro AE111 wich wa a 4A-FTE i think
Offline Profile Quote Post Goto Top

dkae
Stage 3
yeah wrong shape, and also yours says "touring" which is a different car, still under AE111 i think but like a sedan ?

no time to put mine in =.=

BTW, "TruenoSam" dose the arc box just sit in place held by the outlet pipe to the engine. no need to mount the actual ARC box anywhere ?

Offline Profile Quote Post Goto Top

TRUENOSAM
Member Avatar
Stage 6
dkae
Sep 25 2010, 02:48 PM
yeah wrong shape, and also yours says "touring" which is a different car, still under AE111 i think but like a sedan ?

no time to put mine in =.=

BTW, "TruenoSam" dose the arc box just sit in place held by the outlet pipe to the engine. no need to mount the actual ARC box anywhere ?

I think there was supposed to be a mount but mine did not have one. Caused no problems so no bother
Offline Profile Quote Post Goto Top

ky0
Stage 3
will the chamber for an ae101 fit an ae111? looking at robcam's pics, i have the one for an ae101
Offline Profile Quote Post Goto Top

DreadAngel
Member Avatar
Han Lue
There is an extra outlet from memory at the bottom for AE101 compared to AE111 gotta do something about it ;)
Offline Profile Quote Post Goto Top

w00p
Stage 3
^
sorry to bring up an old topic, but i am able to get an ae101 intake chamber for my ae111, the extra outlet is just that little pipe that pokes out the top?
can you just block it off or is there something specific you must do about it?
Offline Profile Quote Post Goto Top

frax
Member Avatar
Stage 6
Should get away with just capping it off bud.
Offline Profile Quote Post Goto Top

w00p
Stage 3
cheers frax :)

i suppose there's no difference in performance/design as the ae101 and ae111 intake chambers are slightly different (ae101 doesn't have the bump right above the where it connects to the plenum) ?
Offline Profile Quote Post Goto Top

Z33kdud3
Stage 6
where can i purchase this?
Offline Profile Quote Post Goto Top

frax
Member Avatar
Stage 6
@ Woop - the ae111 box may have a larger bellmouth in it i think?

@ Zeek - Not sure since ARC are no longer accepting orders. Second hand would be your best bet. May be a bit costly though.
Edited by frax, Apr 3 2011, 08:07 PM.
Offline Profile Quote Post Goto Top

w00p
Stage 3
^ yep, 2nd hand is the only option :(
Offline Profile Quote Post Goto Top

taz-20v
Member Avatar
Stage 6
I would kill for a proper one of these they look great under the bonnet tidies everything up well
