Toyota AE111/4AGE (advanced) electrical wiring diagrams
Topic Started: Oct 18 2011, 12:06 AM (10,659 Views)
AE111_JAMES
Member Avatar
Stage 6
All uploaded in large format so will take time to bring up.

If you not that into electrical wiring this is probably not your cup-of-tea :D

AE111 PFL Dash loom plug pinouts

4AFE ecu edited to 4AGE ecu *part 1*
4AFE ecu edited to 4AGE ecu *part 2*

4E-FE ECU Diagram
4E-FE ECU Diagram *part 2*

Facelift headlight wiring diagram
pre-facelift headlight wiring diagram

AE111 Air conditioning electrical system

AE111 Air conditioning electrical system *Part 2*

AE111 radiator cooling system

4AGE 20v ECU pinout

AE111 Radio wiring

AE111 combination meter diagram
AE111 combination meter diagram 2

4AGE ignition system (same as 5s-fe) *part 1* NOTE: 'see camery'
4AGE ignition system (same as 5s-fe) *part 2* NOTE: 'see camery'

Fuel And engine management

Fuel injector system *part 1*
Fuel injector system *part 2*

Glossary of terms and symbols *part 1*
Gossary of terms and symbols *part 2*

Relay fuse box locations
Relay fuse box locations 2

Facelift AE111 4 bulb headlight wiring diagram
Edited by AE111_JAMES, Sep 10 2017, 10:22 AM.
Offline Profile Quote Post Goto Top

supernova-dw


Thanks very much for posting this up mate!!! Gonna print it all off later on :)
Offline Profile Quote Post Goto Top

import_trung
Member Avatar
Stage 6
hi james.

can you photocopy the pages showing the 3 connectors that sit infront of the ecu. i think they go between the ecu and the dashboard.

i know i got the pinouts from you before, but i was wondering it you have a schematic drawing of it.

thanks
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
sorry for the late reply, yeah i'll try find it for you but I think it doesnt havbe the exact pinouts for those plugs, the wires are just scattered to those plugs, but will have another look when im back at toyota later this week as I have already returned them.
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
.
Edited by AE111_JAMES, Oct 31 2011, 09:11 PM.
Offline Profile Quote Post Goto Top

Turbo
Member Avatar
Stage 5
i need pg64 if possible of the fuel system im havin a problem with my wiring at the moment
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
ok mate, i think i Have that diagram already scanned at home for you so will get it on as soon as possible.
Offline Profile Quote Post Goto Top

Turbo
Member Avatar
Stage 5
thanx so much im suffering tryin ta find the short without a diagram
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
there you are Turbo.
Im not sure but perhaps you asked me earlier for this diagram as for some reason i randomly decided to scan this before i returned the book haha.

hope you are able to find what your looking for :)

I'm working at Toyota tomorrow so will re-check to see whether there is a better diagram for you.
Edited by AE111_JAMES, Nov 2 2011, 06:34 AM.
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
Hi Turbo.
I just found that there is a proper fuel wiring schematic is these two diagrams:
http://www.pictureshack.us/images/22464AFE-4AGE_ECU_wiring_diagram_2.jpg
http://www.pictureshack.us/images/46714AFE-4AGE_ECU_wiring_diagram.jpg
Offline Profile Quote Post Goto Top

Turbo
Member Avatar
Stage 5
thanx for that im still suffering
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
man thats a bugger, whats actually going wrong?
Offline Profile Quote Post Goto Top

Turbo
Member Avatar
Stage 5
efi fuse is blowing and it just happened out of nowhere but i will figure it out the joys of fault finding
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
and does it happen as soon as you put in a new fuse, it blows?
Offline Profile Quote Post Goto Top

Turbo
Member Avatar
Stage 5
yep the second it touches bang fuse gone, i have checked the feed from ecu to fuse and thats ok so gotta check the other side 2morrow was 2 lazy 2day
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
sounds like a definite short to ground.
like you say, possibly the black wire from the battery.

but good luck as diagnosing can be a bitch sometimes lol.
in my case im trying to find out why my engine has a really rough idle and hesitation every now and then.
taring my hair out at this point.
Offline Profile Quote Post Goto Top

Turbo
Member Avatar
Stage 5
ya we both have the same feeling, hopefully find it 2day
Offline Profile Quote Post Goto Top

lombard0
Stage 1
Many thanks for sharing these good stuff man! :)
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
No worries mate, I know how hard it is to get your hands on these, even for the people at Toyota!

We had a case when we were working on a Carib and had to refer to this forum for help lol.
Offline Profile Quote Post Goto Top

import_trung
Member Avatar
Stage 6
james,
Do you have the wiring diagram for the vehicle speedo and rpm?
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
I've got it in the book, I will upload it as soon as my scanner decides to work :/
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
*Bump*

Diagrams have been uploaded for you Trung
Offline Profile Quote Post Goto Top

import_trung
Member Avatar
Stage 6
Excellent. Thanks man. Much appreciated
Offline Profile Quote Post Goto Top

taz-20v
Member Avatar
Stage 6
@ james you seam to know your stuff about wires can you tell me is my tps sensor connector mean to have only 3 wires even though theres 4 pins?
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
yes that right, could have been that our tps is interchangeable with other engines and on our motor we are only needing three.
Offline Profile Quote Post Goto Top

taz-20v
Member Avatar
Stage 6
I have a second question for you james

I have constantly build up of oil inside my vvt solensoid and both the prongs and the connected seam fairly soaked in oil after 5 mins once cleaned
Is this correct?or is my engine head damaged?
Im like a lost sheep with the car I dont have a clue with electrics or sensors
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
With-in the solenoid plunger, oil is ment to be found ther, but how on earth do you get oil in the plug connector!? Haha might be an idea to check the state of the rubber seal, see if its gone hard etc, mine did but couldnt be bothered replacing so just put silicone around where the solenoid meets the head and shes all sweet now.
Your rocker cover seal isnt leaking over the solenoid is it? Lol
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
Next lot is up for you Trung
Offline Profile Quote Post Goto Top

import_trung
Member Avatar
Stage 6
Thanks a million james!!!
Offline Profile Quote Post Goto Top

Levin BZR
Member Avatar


Topic pinned ;)
Offline Profile Quote Post Goto Top

ggutnik
Stage 1
Thank you!
Edited by ggutnik, Aug 16 2012, 04:03 PM.
Offline Profile Quote Post Goto Top

G-rants Ae111
Member Avatar
Stage 2
Awesome diagram of the Radio James.. Cheers bro.
Offline Profile Quote Post Goto Top

nico00
Stage 1
Hi james,

i have cluster AE111GT put on my AE110. The problem is i could found the pin connection location for outside temperature sensor on the cluster, so the display on cluster showing "E" (stand for Error). Would you like to share where is this two wire sensor shall be connect to pin cluster? your help is highly appreciated.
Attached to this post:
Attachments: DSCN0208.jpg (124.71 KB)
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
from what i can see, you need the brown/white wire to pin number 12 and the red/black wire to pin number 13.

im unsure of which plug that one is but it has 2 red wires and two green wires coming from it
Offline Profile Quote Post Goto Top

nico00
Stage 1
AE111_JAMES
Jul 16 2015, 11:08 AM
from what i can see, you need the brown/white wire to pin number 12 and the red/black wire to pin number 13.

im unsure of which plug that one is but it has 2 red wires and two green wires coming from it
Many thanks for your response james, but will you explain more about it. As you can see from the pics, my sensor wires are green white and red yellow, also in the pic, could you inform me which location to be pinned out? A,B,C or D?

Thx
Attached to this post:
Attachments: outside_temperature_sensor.jpg (39.88 KB)
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
all i can say at this point is just try hooking the wires up and see what happens, wont do any damage as its only a signal to the module from the sensor.
Offline Profile Quote Post Goto Top

import_trung
Member Avatar
Stage 6
James.

Do you have any schematics for the abs system?

450hp kinda needs traction control. Lol

Offline Profile Quote Post Goto Top

Ronaldo95163
Stage 2
So I got a dashboard out of an AE111GT to install in my AE110. However it came with the electric AC controls. Mine was manual.

Can someone please provide me with the AC Wiring diagrams pleasee?
The link for it is dead in the first post.
Thanks in advance guys.
Offline Profile Quote Post Goto Top

ales_000
Stage 6
Hopefully James will be on here again in the next couple of days - he's the only one that has all these diagrams.
Offline Profile Quote Post Goto Top

Ronaldo95163
Stage 2
Posted Image

Oh thats good news.
I've been trying to find a pinout/wiring diagram for these controls all over the web but I can't seem to find anything.

All I really need working is the clock,ac on/off, econ on/off and the rear defogger.


Dont really care for the other functions as i never used them on my manual controls.


The temperarure control as well as the fan speed control will work as normal with my existing wiring and cables.
Edited by Ronaldo95163, Jul 26 2017, 03:06 AM.
Offline Profile Quote Post Goto Top

ales_000
Stage 6
I'm guessing it should be similar to a Levin or Trueno that came with manual a/C as all of that stuff looks much the same as on my car with manual controls
Offline Profile Quote Post Goto Top

Ronaldo95163
Stage 2
ales_000
Jul 26 2017, 05:23 AM
I'm guessing it should be similar to a Levin or Trueno that came with manual a/C as all of that stuff looks much the same as on my car with manual controls
Are yours like these?
Posted Image

Those are the manual controls I have as well currently
Offline Profile Quote Post Goto Top

ales_000
Stage 6
No... Mine are more similar to the ones on the AE111GT console that you posted earlier. What I meant by my earlier comment is that the ones on the AE111GT console looked similar to mine, whereas there was a version of the AE111 Levin and Trueno that came out with climate control AC. That version had fully automatic control to achieve a set temperature in the car.

Mine has the electronic buttons as per the AE111GT console, but still the same array of buttons, not the fully automatic electronic climate control version.
Offline Profile Quote Post Goto Top

Ronaldo95163
Stage 2
Ohhh okay lol
I'm hoping that I can get the GT controls working for the functions I want. It should be more or less wiring it back into my existing harness from my current controls hopefully.
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
Damn ill have to redo them all to my dropbox, i should have the a/c scans on my hard drive
let me know if you need anything else

https://www.dropbox.com/sh/y89up9lfiltzy9l/AABfn-DMltZZhq_HuuKwJGYLa?dl=0
Edited by AE111_JAMES, Aug 1 2017, 06:24 AM.
Offline Profile Quote Post Goto Top

Tman17
Stage 1
Hi have you got AE111 combination meter diagram and
AE111 combination meter diagram 2
Thank you
Offline Profile Quote Post Goto Top

AE111_JAMES
Member Avatar
Stage 6
Ive updated all the links, they should work fine now
Edited by AE111_JAMES, Sep 10 2017, 10:23 AM.
Offline Profile Quote Post Goto Top

Tman17
Stage 1
AE111_JAMES
Sep 10 2017, 10:19 AM
Ive updated all the links, they should work fine now
thanks a million
Offline Profile Quote Post Goto Top
